Understanding Native Modules: The Bridge Between Worlds

At its core, a React Native native module is a way to execute native code (Java/Kotlin for Android, Objective-C/Swift for iOS) from your JavaScript code. Think of it as a bridge:

• JavaScript sends a message (a function call with arguments) across the bridge.
• Native code receives the message, performs an operation, and potentially sends a result back.
• JavaScript receives the result (a callback or a Promise).

This bridging mechanism is what allows React Native apps to achieve near-native performance and access platform-specific features that aren't exposed through JavaScript alone.

Setting Up Your Bare Workflow Project

There are two main paths to get an Expo project with native directories:

1. Start a new Bare Workflow project:

   npx create-expo-app --template expo-template-bare-minimum my-native-app
   cd my-native-app


   This command scaffolds a new project with the android and ios directories already present, ready for native development.

2. Migrate an existing Managed Workflow project: If you already have an Expo managed project, you can generate the native directories using:

   expo prebuild


   This command will create the android and ios folders, effectively converting your managed project into a bare-like structure while still allowing you to use most Expo SDK features.

For the purpose of this guide, let's assume you have an Expo project with the android and ios directories available.

Building Your First Custom Native Module: A Simple Example

Let's create a simple native module called CalendarModule that will expose a function to get the current date as a string from the native side. This is a trivial example, but it clearly demonstrates the core concepts.

Android Module

First, open your project in Android Studio (open the android folder).

1. Create the Native Module File: Inside android/app/src/main/java/com/yourprojectname (replace com/yourprojectname with your actual package name, e.g., com/mynativeapp), create a new Java class file named CalendarModule.java.

   // android/app/src/main/java/com/mynativeapp/CalendarModule.java
   package com.mynativeapp;

   import com.facebook.react.bridge.NativeModule;
   import com.facebook.react.bridge.ReactApplicationContext;
   import com.facebook.react.bridge.ReactContextBaseJavaModule;
   import com.facebook.react.bridge.ReactMethod;
   import com.facebook.react.bridge.Callback;
   import com.facebook.react.bridge.Promise;

   import android.util.Log;
   import java.util.Date;
   import java.text.SimpleDateFormat;
   import java.util.Locale;

   public class CalendarModule extends ReactContextBaseJavaModule {
      CalendarModule(ReactApplicationContext context) {
          super(context);
      }

      @Override
      public String getName() {
          return "CalendarModule";
      }

      @ReactMethod
      public void createCalendarEvent(String name, String location, Promise promise) {
          try {
              SimpleDateFormat sdf = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss", Locale.getDefault());
              String currentDate = sdf.format(new Date());
              Log.d("CalendarModule", "Create event called with name: " + name + " and location: " + location + ". Current date: " + currentDate);
              promise.resolve("Event " + name + " at " + location + " created on " + currentDate);
          } catch (Exception e) {
              promise.reject("E_CREATE_EVENT_FAILED", "Could not create event: " + e.getMessage());
          }
      }

      @Override
      public java.util.Map<String, Object> getConstants() {
          final java.util.Map<String, Object> constants = new java.util.HashMap<>();
          constants.put("DEFAULT_EVENT_NAME", "My New Event");
          return constants;
      }
   }


   • getName(): Returns the name of the module that will be used in JavaScript.
   • @ReactMethod: Annotates a method to be exposed to JavaScript. Here, createCalendarEvent takes arguments and uses a Promise to return a result or an error.
   • getConstants(): Allows you to expose constants to JavaScript.

2. Create a React Package: Next, create a new Java class file named CalendarPackage.java in the same directory.

   // android/app/src/main/java/com/mynativeapp/CalendarPackage.java
   package com.mynativeapp;

   import com.facebook.react.ReactPackage;
   import com.facebook.react.bridge.NativeModule;
   import com.facebook.react.bridge.ReactApplicationContext;
   import com.facebook.react.uimanager.ViewManager;

   import java.util.ArrayList;
   import java.util.Collections;
   import java.util.List;

   public class CalendarPackage implements ReactPackage {

      @Override
      public List<ViewManager> createViewManagers(ReactApplicationContext reactContext) {
          return Collections.emptyList();
      }

      @Override
      public List<NativeModule> createNativeModules(ReactApplicationContext reactContext) {
          List<NativeModule> modules = new ArrayList<>();
          modules.add(new CalendarModule(reactContext));
          return modules;
      }
   }


   This package groups your native modules and view managers.

3. Register the Package: Open android/app/src/main/java/com/yourprojectname/MainApplication.java and add your CalendarPackage to the getPackages() list.

   // android/app/src/main/java/com/mynativeapp/MainApplication.java
   package com.mynativeapp;

   import android.app.Application;
   import android.content.Context;
   import android.net.Uri;

   import com.facebook.react.PackageList;
   import com.facebook.react.ReactApplication;
   import com.facebook.react.ReactNativeHost;
   import com.facebook.react.ReactPackage;
   import com.facebook.react.shell.MainReactPackage;
   import com.facebook.soloader.SoLoader;

   import java.lang.reflect.InvocationTargetException;
   import java.util.List;
   import java.util.Arrays;

   public class MainApplication extends Application implements ReactApplication {

     private final ReactNativeHost mReactNativeHost = new ReactNativeHost(this) {
       @Override
       public boolean getUseDeveloperSupport() {
         return BuildConfig.DEBUG;
       }

       @Override
       protected List<ReactPackage> getPackages() {
         @SuppressWarnings("UnnecessaryLocalVariable")
         List<ReactPackage> packages = new PackageList(this).getPackages();
         // Packages that cannot be autolinked yet can be added manually here, for example:
         // packages.add(new MyReactNativePackage());
         packages.add(new CalendarPackage()); // <-- Add your package here!
         return packages;
       }

       @Override
       protected String getJSMainModuleName() {
         return "index";
       }
     };

     @Override
     public ReactNativeHost getReactNativeHost() {
       return mReactNativeHost;
     }

     @Override
     public void onCreate() {
       super.onCreate();
       SoLoader.init(this, /* native exopackage */ false);
       initializeFlipper(this, getReactNativeHost().getReactInstanceManager()); // Remove this line if you don't want Flipper enabled
     }

     /**
      * Loads Flipper in `debug` build type. Assumes Flipper library has been added to the `devDependencies` in `package.json`.
      * @param context
      * @param reactInstanceManager
      */
     private static void initializeFlipper(Context context, ReactInstanceManager reactInstanceManager) {
       if (BuildConfig.DEBUG) {
         try {
           /*
            We use reflection here to pick up the class that initializes Flipper,
            since Flipper library is not available in release code
           */
           Class<?> aClass = Class.forName("com.mynativeapp.ReactNativeFlipper");
           aClass
               .getMethod("initializeFlipper", Context.class, ReactInstanceManager.class)
               .invoke(null, context, reactInstanceManager);
         } catch (ClassNotFoundException e) {
           e.printStackTrace();
         } catch (NoSuchMethodException e) {
           e.printStackTrace();
         } catch (IllegalAccessException e) {
           e.printStackTrace();
         } catch (InvocationTargetException e) {
           e.printStackTrace();
         }
       }
     }
   }


iOS Module

Now, let's set up the iOS part. Open your project's ios folder in Xcode.

1. Create the Native Module Files: In Xcode, right-click on your project name in the Project Navigator, then choose New File.... Select Objective-C File and name it CalendarModule. Xcode will ask if you want to create a bridging header. Choose Create Bridging Header if it's a new project or if you don't have one. This is crucial if you plan to mix Objective-C and Swift, or use Swift in your module.

   CalendarModule.h:

   // ios/CalendarModule.h
   #import <React/RCTBridgeModule.h>
   #import <React/RCTEventEmitter.h>

   @interface CalendarModule : RCTEventEmitter <RCTBridgeModule>

   @end


   CalendarModule.m:

   // ios/CalendarModule.m
   #import "CalendarModule.h"
   #import <React/RCTLog.h>

   @implementation CalendarModule

   // To export a module named CalendarModule
   RCT_EXPORT_MODULE();

   // Example method, exposed to JavaScript
   RCT_EXPORT_METHOD(createCalendarEvent:(NSString *)name location:(NSString *)location resolver:(RCTPromiseResolveBlock)resolve rejecter:(RCTPromiseRejectBlock)reject)
   {
     NSDateFormatter *dateFormatter=[[NSDateFormatter alloc] init];
     [dateFormatter setDateFormat:@"yyyy-MM-dd HH:mm:ss"];
     NSString *currentDate = [dateFormatter stringFromDate:[NSDate date]];

     RCTLogInfo(@"Pretending to create an event %@ at %@. Current date: %@", name, location, currentDate);
     if (name) {
         resolve([NSString stringWithFormat:@"Event %@ at %@ created on %@", name, location, currentDate]);
     } else {
         reject(@"E_CREATE_EVENT_FAILED", @"Event name cannot be empty", nil);
     }
   }

   // To expose constants to JavaScript
   - (NSDictionary *)constantsToExport
   {
     return @{ @"DEFAULT_EVENT_NAME": @"My New Event" };
   }

   // We don't want to export any events for this simple module
   - (NSArray<NSString *> *)supportedEvents
   {
     return @[];
   }

   @end


   • RCT_EXPORT_MODULE(): Registers the module with React Native, making it available via NativeModules.CalendarModule.
   • RCT_EXPORT_METHOD(): Exposes a method to JavaScript. The arguments resolver and rejecter are for Promises.
   • constantsToExport: Similar to Android's getConstants(), this exposes constants.

JavaScript Interface

Now that the native modules are set up, let's access them from our React Native JavaScript code.

Open App.js or any other component where you want to use the module.

// App.js
import React from 'react';
import { SafeAreaView, StyleSheet, Text, Button, NativeModules, Alert } from 'react-native';

const { CalendarModule } = NativeModules;

function App() {
  const onCreateEventPress = async () => {
    try {
      const eventName = CalendarModule.DEFAULT_EVENT_NAME; // Accessing a constant
      const result = await CalendarModule.createCalendarEvent(
        eventName,
        'My Awesome Location'
      );
      Alert.alert('Event Created', result);
    } catch (e) {
      Alert.alert('Error', e.message);
      console.error(e);
    }
  };

  return (
    <SafeAreaView style={styles.container}>
      <Text style={styles.title}>Native Module Example</Text>
      <Text style={styles.description}>Using CalendarModule to create an event.</Text>
      <Button title="Create Calendar Event" onPress={onCreateEventPress} />
    </SafeAreaView>
  );
}

const styles = StyleSheet.create({
  container: {
    flex: 1,
    justifyContent: 'center',
    alignItems: 'center',
    backgroundColor: '#F5FCFF',
  },
  title: {
    fontSize: 24,
    fontWeight: 'bold',
    marginBottom: 20,
  },
  description: {
    fontSize: 16,
    textAlign: 'center',
    marginHorizontal: 30,
    marginBottom: 30,
  },
});

export default App;

After making these changes, rebuild your native apps. For Android, run npx react-native run-android or build from Android Studio. For iOS, run npx react-native run-ios or build from Xcode. You should now see the button, and pressing it will trigger your native module!

Bridging Data Types and Complex Operations

The example above used simple strings and Promises. React Native's bridge supports a variety of data types:

• Strings, Numbers, Booleans: Passed directly.
• Arrays: Converted to ReadableArray (Android) or NSArray (iOS).
• Objects: Converted to ReadableMap (Android) or NSDictionary (iOS).
• Callbacks: For asynchronous results, functions can be passed and invoked from native code.
• Promises: A cleaner way for asynchronous operations, especially when only one result (success/failure) is expected.

When dealing with more complex data, you'll often serialize it to JSON strings on the JavaScript side, pass it to native, deserialize, perform operations, and then serialize the result back to a JSON string before returning it to JavaScript. This ensures compatibility across the bridge.

Testing Your Native Module

Testing is crucial when working with native modules:

• Emulators/Simulators: Always test on both Android emulators and iOS simulators to catch platform-specific issues early.
• Physical Devices: Critical for features that rely on actual hardware (e.g., camera, Bluetooth, sensors). Issues often appear differently on real devices.
• Debugging Native Code: Use Android Studio's debugger for Java/Kotlin and Xcode's debugger for Objective-C/Swift. This allows you to step through your native code and understand exactly what's happening.

Tips for a Smooth Development Experience

• Keep Native Code Modular: If you're building a complex feature, consider breaking it into smaller, manageable native modules or helper classes.
• Understand Native Build Systems: Familiarize yourself with Gradle (Android) and Xcode build settings (iOS). This knowledge becomes invaluable for troubleshooting build errors, linking libraries, or configuring permissions.
• Clear node_modules and Metro Cache: Sometimes, when making native changes, you might encounter stale caches. Running rm -rf node_modules && npm install && npx expo start --clear can often resolve these.
• Use LogCat (Android) and RCTLogInfo (iOS): For debugging, use native logging mechanisms to see what your native code is doing.
• Version Control: Commit your android and ios directories to version control. Treat them as integral parts of your project.

Publishing Your Bare Workflow App

Once you've integrated your native modules, the publishing process for a bare workflow app differs from the managed workflow. You can no longer use the classic expo build command.

The recommended approach is to use EAS Build. EAS (Expo Application Services) is designed to handle builds for both managed and bare workflow projects, including those with custom native modules. It streamlines the process of generating app binaries (.apk, .aab for Android; .ipa for iOS) in the cloud, handling signing, provisioning profiles, and more.

Alternatively, you can build manually using Android Studio for Android and Xcode for iOS, just like you would with a vanilla React Native project. However, EAS Build significantly reduces the complexity and setup involved.

Conclusion

Embracing the Expo Bare Workflow and integrating custom native modules opens up a world of possibilities for your React Native applications. While it adds a layer of complexity by requiring you to dive into platform-specific code, it's a powerful skill that allows you to overcome the limitations of purely JavaScript-based development and build truly custom, high-performance mobile experiences.

Don't let the idea of native code intimidate you. Start with simple modules, experiment, and gradually build up your expertise. The ability to bridge JavaScript with native power will make you a much more versatile and capable mobile developer.

Do you have a unique mobile app idea that requires deep native integration? Or are you looking for a full-stack developer to bring your vision to life? Feel free to get in touch – I'd love to help you build something amazing.
